D700/750 E2-E3
ELECTRIC SYSTEM
Nominal voltage V
12 12 12
Alternating current generator (nominal voltage) V
14 14 14
Alternating current generator (nominal current) A
55 55 55
Starter motor output kW
2,3 2,3 2,3
Recommended battery capacity Ah
92 110 110
Battery breakaway current A
450 880 880
SUCTION CIRCUIT
Maximum depression allowed with new air
filter
mbar
15 15 15
Model D703 E3 D703 TE3 D703 IE3
These technical data and specifications re-
fer exclusively to standard VM MOTORI
S.P.A. engines.
TECHNICAL DATA (D753 E3-TE3-IE3)
Model D753 E3 D753 TE3 D753 IE3
DIMENSIONS
A mm 592,5 592,5 592,5
B mm 516 534 533,5
C mm 669,1 706,3 713,2
GENERAL DATA
Cycle Four stroke diesel
Total displacement litri 2,228 2,228 2,228
Number of cylinders n. 3 3 3
Bore and stroke mm 94x107 94x107 94x107
