XTS-IP / XTSc-IP Station User Guide March 2007
Features Description
1 = Handset Used to listen/speak when on a call in handset mode.
2 = Headphone When using a headphone, button toggles headphone state.
3 = Speaker Used to listen to a caller in handsfree mode when in speaker
mode.
4 = Speed Button Used to access speed dialing, save number redial, and last
number redial. This button is also used to access flexible button
programming.
5 = DND Button The DND (Do Not Disturb) feature blocks all incoming calls.
When DND is active, the red LED in this button is illuminated.
6 = Speaker Button Used to toggle between speaker & handset modes when in
speakerphone state. Button is red when speakerphone is active.
7 = Hold/Save Button Used to hold calls and to retrieve held calls.
8 = 3 Soft Buttons Used to work in conjunction with fixed and flexible features.
9 = LCD Display Shows information about telephone status, dialing directories,
and text messages.
10 = Ring LED Illuminates when the phone is ringing.
11 = Trans/PGM Button Used to transfer an intercom or outside call from one station to
another.
12 = Flexible Buttons The 24 flexible buttons are used to access outside lines or
call-handling features.
13 = Call Back Button Used to initiate a call back request to a busy station. Once that
station becomes idle, the initiating station is signaled.
14 = Volume Bar Adjusts the level of tones, background music, ringing, and
receiver volume
15 = MIC (Microphone) Used to speak to a caller in a handsfree mode when in speaker
mode.
16 = Menu Button Used to move to the desired option(Dial, MSG, Program), and to
select the next screen when indicated by an arrow on the LCD
display.
17 = Phone Book Used to access speed dialing, save number redial, and last
number redial, and to access flexible button programming.
To Next Page
