72 IP Phone
XTS-IP / XTSc-IP Station User Guide March 2007
Default Flexible Button Map
LCD Display
The display for the 8 button IP7008D supports 2 rows by 24 characters.
Backlight Display
The IP7008D phones are enhanced to allow backlight of the LCD. The
backlight feature can be set to always be on, always be off, or on when
the phone is in use.
If the setting is “on when the phone is in use”, the backlight will remain
lit after going to the idle state for the period of time established in the
Backlight Display Timer programming.
To use the Backlight Display feature:
Dial feature code[ 637] to cycle through the options:
Off, On, and In Use .
CONDITIONS
The Message Waiting LED is controlled by:
Flash 50/51, Page B, Button 15 (Light Control) can be variable
assignment.
Station 100 Station 101
Loop Pool
Call Back Pickup
DND VM
STA 1234 NAME
NOV 10 05 11:04 am
