Troubleshooting ChartVoith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Diagnosis and Troubleshooting
Voith Turbo I 153.00009710 I arrtd I 2005-11 © 2005
A
FLASHING?
IO
NIO
Check the
operation (for
retarder braking,
nominal speed
of the engine,
if possible)
IO
NIO
Check
temperature
sensors
(oil/coolant)
Replace
temperature
sensor
Check vehicle
cooling system
in accordance
with the
information from
the vehicle
manufacturer
IO = in order
NIO = not in order
On-board diagnosis is possible if the
OEM equipment allows it (display).
Observe the specifications of the
vehicle manufacturer.
*
Retarder
pilot light
(standard
type)*
Temperature
adaptation
Instruct the driver!
*
28014_en
(see page 84 onw.)
