Page 51
Voith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Repair
Voith Turbo I 153.00009710 I arrtd I 2005-11
© 2005
7. Repair
7.1 Components Overview 52
7.2 Top Oil Tank Cover 59
7.3 Bottom Oil Tank Cover 61
7.4 Casing Ventilation 63
7.5 Retarder Ventilation 69
7.6 Water Neck 70
7.7 Heat Exchanger 71
7.8 Pressure Control Valve 76
7.9 Non-Return Valve Inlet 79
7.10 Non-Return Valve Outlet 81
7.11 Oil Temperature Sensor 84
7.12 Coolant Temperature Sensor 86
7.13 Pressure Sensor 88
7.14 Proportional Valve and Damping Plate 89
