Page 4
Voith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Table of Contents
Voith Turbo I 153.00009710 I arrtd I 2005-11
© 2005
7.10 Non-Return Valve Outlet 81
7.11 Oil Temperature Sensor 84
7.12 Coolant Temperature Sensor 86
7.13 Pressure Sensor 88
7.14 Proportional Valve and Damping Plate 89
8 Appendix 91
8.1 Tightening Torques 92
