Page 43
Proportional Valve CurrentVoith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Diagnosis and Troubleshooting
Voith Turbo I 153.00009710 I arrtd I 2005-11
© 2005
7. Read measured value and compare to the
specified values:
8. Disconnect multimeter.
9. Pull the plug from the measuring adapter (99/3)
and connect it to the proportional valve (3700).
Due to continuous readjustment in the control loop,
the measured values may not be constant, but are
within the specified range.
Controller Item number/
Code number
Measured
value
Digiprop 138, 152, 155 396–596 mA
150 365–565 mA
151 379–579 mA
153 423–623 mA
157, 158 409–609 mA
159 534–546 mA
179, 180,
502, 504, 508, 512,
514
440–640 mA
510 430–630 mA
NOTE
Controller Item number/
Code number
Measured
value
VERA
TM
H67.2763.xx 440–640 mA
H67.2866.xx
H67.3449.xx
H67.3457.xx
H67.3658.xx
153.000586.xx
