Page 75
Heat ExchangerVoith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Repair
Voith Turbo I 153.00009710 I arrtd I 2005-11
© 2005
6. With housing models up to retarder serial number
963 690, the gap at the top between the heat
exchanger (6400) and the retarder housing (100)
must be sealed with sealing agent (arrow) (see
dashed line/figure).
100
6400
28175
