Oil Temperature SensorVoith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Repair
Voith Turbo I 153.00009710 I arrtd I 2005-11 © 2005
Checking the internal resistance
Measuring in one temperature range is usually
sufficient.
Polarity is irrelevant.
Temperature Resistance
20 °C ± 10 °C 1039–1117 Ω
60 °C ± 10 °C 1194–1271 Ω
80 °C ± 10 °C 1271–1347 Ω
NOTE
