Tightening TorquesVoith Turbo I Aftersales Service Manual Voith Retarder VR 115 E I Appendix
Voith Turbo I 153.00009710 I arrtd I 2005-11 © 2005
4100 Screw plug M30x1.5, hexagon socket head, w.a.f. 17 With copper sealing ring: 130 Nm
With integrated sealing ring: 100 Nm
4200 Screw plug M24x1.5, hexagon socket head, w.a.f. 12 With copper sealing ring: 80 Nm
With integrated sealing ring: 47 Nm
5200/1 Oil temperature sensor M14x1.5, hexagon insert bit, w.a.f. 21 32 Nm
5200/2 Coolant temperature sensor M14x1.5, hexagon insert bit, w.a.f. 21 32 Nm
5700 Combined hex head screw M8x25, hexagon insert bit, w.a.f. 13 30 Nm
6600 Combined hex head screw M14x45, hexagon insert bit, w.a.f. 22 150 Nm
9000 Pressure sensor M16x1.5, hexagon insert bit, w.a.f. 27 32 Nm
20200 Screw plug M8x80, hexagon insert bit, w.a.f. 13 30 Nm
20300 Screw plug M14x1.5, hexagon insert bit, w.a.f. 13 32 Nm
25200 Hex head screw M10x70, hexagon insert bit, w.a.f. 16 58 Nm
25300 Hex head screw M10x60, hexagon insert bit, w.a.f. 16 58 Nm
Item No. Designation Dimensions Tightening torque
