Issue: 01
Page: 10-2
Operating instructions
VOLLMER WERKE
MAP 200 / 400
10.2 Standard adjustment
Note
The values indicated below are given as an indication and can vary depending on
the steel quality and saw blade shapes.
Levelling tolerance
Recommended value : 0,02 mm
Pitch between two paths
< 100 10
100 – 150 12
150 – 200 14
200 – 300 16
300 – 400 18
mm
mm
Cycle number
Recommended value : 5
Tightening pressure of driving rollers
Pressure factory set : 3,5 bar
Note
It’s advisable to eliminate every grease mark, lubricant, resin and other impurities
on the saw blade before proceeding.
