VOLTCRAFT DSO Four-Channel Series User Manual

4.Advanced User Guidebook
70
External
Save the waveform onto a USB memory
device
Insert
a USB memory device into the port on
the front panel. If the icon
appears on the
top right of the screen, the USB memory
device is installed successfully
. If the USB
memory device cannot be recognized, format
the USB memory device according to the
methods in "USB disk Requirements" on P60
.
The name is default as current system date and
time. The cloned waveform will be saved
onto
the USB memory device as a OTA file.
Output
(Generator is available and internal storage is selected)
Output the waveform stored in the selected object.
The following steps take the oscilloscope with dual-channel AG for instance.
To save the CH1 waveform and save to the internal/USB memory:
(1) Push Save button.
(2) Select Type in the bottom menu, turn the M knob to select Clone in the left
menu.
(3) Select Source in the bottom menu, select Mode as Out1. in the right menu.
(4) Select AG Output Out1 as CH1. in the right menu.
(5) Select Line in the bottom menu. If a or b is selected, turn the M knob to move the
cursor. If ab is selected, turn the M knob to move the pair of cursors. If x is
selected, the entire screen will be selected automatically.
(6) Select Save in the bottom menu.
 To save the waveform to internal memory, select Storage in the right menu
as Internal. Turn the M knob to select an object in the left menu, select Save
in the right menu.
 To save the waveform onto a USB memory device, select Storage in the
right menu as External. Select Save in the right menu. An input keyboard
used to edit the file name will pop up. Turn the M knob to select the keys,
push the knob to input. Select the key in the keyboard to confirm. The
cloned waveform will be saved onto the USB memory device as a OTA file.
To output the waveform stored in the internal memory through the generator:
(The generator is optional.)
(1) Push Save button.
(2) Select Type in the bottom menu, turn the M knob to select Clone in the left
menu.
(3) Select Save in the bottom menu, select Storage as Internal in the right menu.
(4) Turn the M knob to select an object in the left menu.
