1Alternating current
Range Accuracy Resolution
60.00 A
±(2.5% + 5)
0.01 A
600.0 A 0.1 A
Frequency range 50 - 60 Hz; Overload protection 750 V, 1000 A
Measuring point error: accuracy deviation in case of non-centered measuring point: ±1%
WhentheinputACcurrent≥10Afrequencyisdisplayed
True RMS crest factor (CF): max. 3.0
CF >1.0 - 2.0 + 3%
CF >2.0 - 2.5 + 5%
CF >2.5 - 3.0 + 7%
2Direct current
Range Accuracy Resolution
60 A
±(2.5% + 5)
0.01 A
600 A 0.1 A
Overload protection 1000 V, 1000 A
DC accuracy: After successful zero adjustment
Measuring point error: accuracy deviation in case of non-centered measuring point: ±1%
