VOLTCRAFT VC-590OLED - Page 75

3AC voltage
Range Accuracy Resolution
6.000 V
±(1.2% + 3)
0.001 V
60.00 V 0.01 V
600.0 V 0.1 V
750 V ±(1.5% + 5) 1 V
Frequencyrange45-400Hz;Overloadprotection750V;Resistance:10MΩ
WhentheinputACvoltage≥100mVRMSfrequencyisdisplayed
True RMS crest factor (CF): max. 3.0
CF >1.0 - 2.0 + 3%
CF >2.0 - 2.5 + 5%
CF >2.5 - 3.0 + 7%
4Direct current voltage
Range Accuracy Resolution
6.000 V
±(0.8% + 3)
0.001 V
60.00 V 0.01 V
600.0 V 0.1 V
1000 V ±(1.0% + 5) 1 V
Overloadprotection1000V;Resistance:10MΩ
75
