REMOTE OPERATION
PM1000+ Power Analyzer User Manual © Voltech 2010 Page 41
":GRA:HRM:VLT:SCL <value>”
Set scaling in harmonic bar chart for Volts
<value> = 0 - 1000
":GRA:HRM:AMP:SCL<value>”
Set scaling in harmonic bar chart for Amps
<value> = 0 - 100
":GRA:HRM:AMP:SHW”
Show current bar chart
":GRA:HRM:VLT:SHW”
Show voltage bar chart
":GRA:HRM:HLT”
Highlights required harmonic "value" = 1
through 50
":GRA:WAV:WAT <value>”
<value> = 0 → Watts graph disabled
<value> = 1 → Watts graph enabled
":GRA:WAV:SHW”
Show waveform graph
":HMX:VLT:SEQ <value>”
Sets odd or odd/even harmonics:
<value> = 0 → odd/even
<value> = 1 → odd only
":HMX:VLT:RNG <value>”
Sets harmonic range <value> = 1 - 50
":HMX:VLT:FOR <value>”
Sets voltage harmonic format:
<value> = 0 → Absolute values
<value> = 1 → Percentage of fundamental
":HMX:AMP:SEQ <value>”
Sets odd or odd/even harmonics:
<value> = 0 → odd/even
<value> = 1 → odd only
":HMX:AMP:RNG <value>”
Sets harmonic range <value> = 1 - 50
":HMX:AMP:FOR <value>”
Sets current harmonic format:
<value> = 0 → Absolute values
<value> = 1 → Percentage of fundamental
":HMX:THD:FML <value>"
Select the THD formula :
<value> = 0 → series
<value> = 1 → difference
":HMX:THD:SEQ <value>"
Select the THD sequence:
<value> = 0 → All
<value> = 1 → odd only
":HMX:THD:RNG <value>"
Set the THD range <value> = 2 to 50.
