Warning!
Completely tilt the cab! It is not
permissible to work underneath a
cab which is not fully tilted. If the
cab cannot be completely tilted, a
suitable metal device must be
inserted to ensure that the cab
cannot fall back again. Never go
beneath or in front of a tilted cab.
Mechanical tilting
Tilting
1 Check that
• there is sufficient space in front of the cab.
• the hand-operated parking brake is on.
• the gear lever is in neutral position.
• the doors are either completely open or
properly shut.
• the cap on the clutch fluid reservoir is
properly closed.
2 Fit the socket spanner (3) into the valve of the
hydraulic pump (1).
3 Turn clockwise to the stop position. The valve is
closed.
4 Get the pump rod.
5 Assemble the lever with the socket spanner (3).
6 Place the socket spanner in the pump (2).
7 Pump until the cab has reached maximum tilt.
J8008488
J0008203
Cab
355
