Tilting back
1 Fit the socket spanner (3) into the valve of the
hydraulic pump (1).
2 Turn anticlockwise to the stop position. The
valve is open.
3 Get the pump rod.
4 Assemble the lever with the socket spanner (3).
5 Place the socket spanner in the pump (2).
6 Pump until the cab is locked in the driving
position.
7 Check that the lamp showing unlocked cab does
not light up when the engine is running.
8 Put the tools away.
J0008208
Open valve (drive position)
J3014610
Control lamp for tilted cab.
Electric tilting
Tilting
1 Check that:
• there is sufficient space in front of the cab.
• the hand-operated parking brake is on.
• the gear lever is in neutral position.
• the doors are either completely open or
properly shut.
• the cap on the clutch fluid reservoir
2 Fit the socket spanner (3) into the valve of the
hydraulic pump (1).
3 Turn clockwise to the stop position. The valve is
closed.
4 Turn the ignition to the radio position.
J8008489
356
Cab
