VTech IS7121A User Manual

SET UP THE TELEPHONE
15
You may install the doorbell on the left or right side. The diagram below demonstrates an example
of doorbell camera position to view a visitor about 20 inches from the camera. The camera in this
example is set in 10 degrees angle to the right.
Top view
Shooting area
19.7 inches
60 degrees
22.8 inches
Shooting area
19.7
inches
50 degrees
18.3
inches
63 inches
60 degrees
Shooting area
24 inches
20 inches
After you have tested the reception range and found the desirable location to install the doorbell,
press END on the handset to end the video streaming and proceed to Install the Doorbell Wall
Mount Cover and Install the Doorbell.
