Ignition System BTS Repair
wc_tx000299gb.fm 10
4. Ignition System
4.1 Checking the spark plug
See Graphic: wc_gr001388
4.1.1 Remove filter hood.
4.1.2 Pull spark plug socket (1) off the spark plug and remove spark plug (2).
4.1.3 Connect spark plug (2) with plug socket and hold to ground (3). Pull out
starter cable. If no spark is produced, repeat procedure with new spark
plug.
Note: Switch (4) must be in position “I”.
4.1.4 Combustion and motor performance will be improved if the spark plugs
function properly. Dirty or faulty spark plugs should therefore be
cleaned or replaced.
• The spark plug pictured (a) has serious oil carbon deposits.
Clean or replace spark plug.
• This spark plug (b) is showing signs of wear (burning off) on the
middle electrode. Spark plug must be replaced.
S
T
O
P
1
0,5 mm
2
1
4
3
2
wc_gr001388
b
a
