BTS Repair Table of Contents
wc_br0118754enTOC.fm 1
1. Technical Data 5
1.1 BTS 930 / BTS 935 / BTS 1030 / BTS 1035 ........................................ 5
2. Special Tools 6
3. Clutch 7
3.1 Dismantling the clutch/drum ................................................................. 7
3.2 Mounting muffler and heat plate ........................................................... 8
3.3 Repairing the clutch .............................................................................. 8
3.4 Mounting the clutch/drum ..................................................................... 9
4. Ignition System 10
4.1 Checking the spark plug ..................................................................... 10
4.2 Replacing the plug connector ............................................................. 11
4.3 Removing/assembling the ignition / short circuit cable ....................... 12
4.4 Removing/checking/mounting the ignition armature .......................... 14
4.5 Removing/mounting the flywheel ....................................................... 15
5. Starting System 16
5.1 Removing/mounting the starter / return spring ................................... 16
5.2 Pretensioning/checking the return spring ........................................... 17
5.3 Replacing the starter ratchet .............................................................. 17
6. Carburetor 18
6.1 Setting the carburetor ......................................................................... 18
6.2 Removing the carburetor and intake hose ......................................... 19
6.3 Carburetor - dismantling/testing the control side ................................ 20
6.4 Carburetor - dismantling/testing the pump side .................................. 21
6.5 Carburetor - Cleaning the fuel filter .................................................... 21
