BTS Repair Ignition System
wc_tx000299gb.fm 15
4.5 Removing/mounting the flywheel
See Graphic: wc_gr001395
Removing
4.5.1 Block the piston using the piston stop wedge.
4.5.2 Unscrew bolt (2) and remove washer (3).
4.5.3 Remove flywheel with pulling device 0037576 (a).
CAUTION: To avoid damage to the crankshaft, always use the
protective cap included with the pulling device.
Mounting
4.5.1 Before mounting the flywheel, the cone seat and the crankshaft (4)
must be cleaned.
4.5.2 The flywheel is tightened with a torque of 23 ft.lbs. (30 Nm).
wc_gr001395
2
3
a
4
