BTS Repair Fuel Tank / Fuel Filter
wc_tx000304gb.fm 25
9. Fuel Tank / Fuel Filter
9.1 Removing/inserting the ventilation valve
See Graphic: wc_gr001406
Removing
Push the ventilation valve with a pin into the tank (arrow) and remove
with pointed pliers through the filler opening (a).
Inserting
Press the new ventilation valve with a pin into the housing until the
white sinter plastic projects about 2–3 mm beyond the tank (b).
9.2 Replacing the throttle lever mechanism
See Graphic: wc_gr001406
Push the two cylindrical pins (1) out of the handle dish (2).
The throttle lever (3), spring (4) and throttle lock (5) may now be
removed.
The throttle lock pin (6) for half throttle can also now be replaced.
2-3mm
(.080”-0.12”)
3
1
5
6
2
b
a
wc_gr001406
