13. Torques
13.1 BTS 930 / BTS 935 / BTS 1030 / BTS 1035
Assembly set Nm (ft.lbs.)
Muffler 10 + 1 (7) **
Crankcase 10 + 1 (7) **
Cylinder 14 + 1 (10) **
Ignition coil 6 + 1 (53 in.lbs.) **
Front handle 7 ± 0.5 (60 in.lbs.)
Rubber mounts 7 ± 0.5 (60 in.lbs.)
Carburetor 1.5 ± 0.5 (13 in.lbs.)
Clutch 55 ± 0.2 (40)
Flywheel 30 ± 2.5 (22)
Spark plug 25 ± 2.5 (19)
V-belt pulley 25 + 5 (19)
** Screws with locking serration
