1.2 Overall view of machine
Fig. 1: Machine outside views
1 Control stand/handle
2Skip
3 Loader unit (option)
4 Engine
5 Travelling drive
6
Eye hook for loading/tying down the
machine
7 Undercarriage
8Track
9 Foothold
10 Engine cover
11 Auxiliary hydraulics (option)
1
2
3
6
4
10
6
9
5
7
8
2
1
6
11
7
5
8
