5-18 BA DT08 SL EN – Edition 1.0 * * dt08b530.fm
Maintenance
Decreasing track tension
☞ Park the dumper on firm and level ground
☞ Raise the dumper with suitable means
☞ Tracks should be raised off the ground
☞ Stop the engine
☞ Use additional supports for the dumper and ensure that it cannot overturn
☞ Unscrew set screw D with a suitable tool
➥ The fork E is retracted
➥ The track is slackened
☞ Check track tension
➥ Repeat the procedure if track tension is too low or too high
Fig. 85: Decreasing track tension
D
E
