BA DT08 SL EN – Edition 1.0 * dt08b520.fm 5-11
Maintenance
Replacing the filter (petrol engine)
Replace filter cartridge A as follows:
☞ Stop the engine
☞ Unscrew wing nut B off cover C
☞ Remove cover C
☞ Unscrew wing nut D off filter cartridge A
☞ Insert the new filter cartridge A
☞ Tighten wing nut D on filter cartridge A
☞ Ensure that all dirt (dust) inside the cover C has been removed
☞ Position cover C (ensure that it is properly seated)
☞ Tighten wing nut B again on cover C
Dispose of filter cartridge A in an environmentally friendly manner.
Fig. 79: Cleaning/replacing the DT08-P filter (petrol
engine)
A
B
C
D
