BA DT08 SL EN – Edition 1.0 * dt08b330.fm 3-21
Operation
Loading and transporting the machine
Safety instructions
• The transport vehicle must be of sufficient size. See Chapter 6 “Specifications” for
the dimensions and the weight of the machine!
• Remove any mud, snow or ice from the tracks so that the machine can be safely driven
onto the ramps
• Secure the machine against unintentional movement – see Parking the machine on
page 3-19!
The machine must be loaded and transported properly –
Danger of accidents!
☞ It is essential that you read the safety instructions at the beginning of this
chapter and follow any other safety instructions relevant in your country!
Load as follows:
☞ Secure the transport vehicle with chocks to prevent it from rolling
☞ Place the access ramps at the smallest possible angle. Ensure that the grade does not
exceed 15° (27 %). Use access ramps with an antiskid surface only.
☞ Ensure that the loading area is clear and access to it is not obstructed – e.g. by super-
structures
☞ Ensure that the ramps and the tracks of the dumper are free of oil, grease and ice
☞ Start the engine of the dumper
☞ Lower the skip
☞ Raise the loader unit enough so that it will not touch the access ramps
☞ Carefully drive the dumper onto the middle of the transport vehicle
☞ Lower the loader unit to the loading area
☞ Stop the engine
☞ Remove the ignition key (option)
The manufacturer’s warranty shall not apply to accidents or damage caused by
loading or transporting the machine.
<17°
Fig. 54: Access ramps
< 17°
<
