Wacker Neuson DT08-D

6-36 BA DT08 SL EN – Edition 1.0 * * dt08b610.fm
Specifications
6.10 Dimensions model DT08-D with skip
830
700
180
790
174
234
1
3
°
3871660
2520
518753392
1320
45 750
386
1845
420
1240
1313
Fig. 89: Machine dimensions (model DT08-D with skip)
Main data
Model DT08-D
Payload
500 kg
Dead weight incl. skip and loader unit
560 kg
Length
1660 mm
Width
790 mm
Height
1313 mm
Foothold projection
387 mm
Track width
180 mm
Ground contact length of tracks
753 mm
Front skip projection
392 mm
Skip load height (front edge)
750 mm
Skip length
1320 mm
Skip width
700 mm
Skip depth
386 mm
Scraping depth
45 mm
