Wacker Neuson EZ26 - Page 127

BA EZ26 en/us* 1.0 * EZ26_01_510.fm 5-17
Operation 5
Swiveling the boom
Press and hold button A on the control lever base on the left.
Swiveling the boom to the right:
Press pedal B forward.
Swiveling the boom to the left:
Press pedal B to the rear.
Swiveling the boom (proportionally controlled)
Swiveling the boom to the right:
Press pedal B forward.
Swiveling the boom to the left:
Press pedal B to the rear.
Fig. 136:
A
Fig. 137:
B
Fig. 138:
B
