Wacker Neuson EZ26 - Page 236

9-4 BA EZ26 en/us* 1.0 * EZ26_01_900.fm
9 Technical data
Fuses/relays
The fuse box A is located on the left of the engine compartment.
1. Opening:
1. Stop and park the vehicle Stop the engine
- See “Preparing lubrication”.
2. Open the engine cover.
3. Loosen screw B and remove the cover.
Closing:
1. Install the cover and tighten screw B.
Fig. 265
B
A
Fig. 266
F5F3 F8F4 F7
F9
F10
F2F1
F6
K7
K58 V1
K6
K9
K8
