Technical data 9
Assignment
Relays
Fuses
F1 Start, preheat, cutoff solenoid
F2
Starter, air-pressure sensor/output adaptation (Yan-
mar 3TNV80F-SNNS)
F3
Display, cutoff solenoid, relays, overload pressure
switch
F4 Boom working light, heating
F5 Cabin roof lights
F6 Valves, horn, travel signal
F7 Wiper, interior light
F8
Proportional auxiliary hydraulics (AUX I)
Proportional 3rd control circuit (AUX II)
F9 Rotating beacon, radio
F10 Socket, 12 V power outlet
Relays
V1 Blocking diode
K6 Preheating time lag relay (blue)
K7 Starting relay
K8 Preheating time lag relay (brown)
K9 Cutoff solenoid
K58 Speed range 2
