Technical data 9
EZ26
A Height 2414 mm (95 in)
B1 Cabin width 986 mm (39 in)
B2 Upper carriage width 1366 mm (54 in)
B3 Travel gear width 1570 mm (62 in)
C1 Transport length (short stick) 4266 mm (14')
C2 Transport length (long stick) 4290 mm (14'-1'')
D1 Max. digging depth (short stick) 2537 mm (8'-4'' in)
D2 Max. digging depth (long stick) 2737 mm (9'-0'')
E1 Max. vertical digging depth (short stick) 1949 mm (77 in)
E2 Max. vertical digging depth (long stick) 2139 mm (84 in)
F1 Max. digging height (short stick) 4176 mm (13'-8'')
F2 Max. digging height (long stick) 4306 mm (14'-2'')
G1 Max. tilt-out height (short stick) 2847 mm (9'-4'')
G2 Max. tilt-out height (long stick) 2977 mm (9'-9'')
H1 Max. reach at ground level (short stick) 4490 mm (14'-9'')
H2 Max. reach at ground level (long stick) 4690 mm (15'-5")
K1 Max. digging radius (short stick) 4624 mm (15'-2'')
K2 Max. digging radius (long stick) 4816 mm (15'-10'')
M Max. boom displacement to bucket center (right side) 765 mm (30 in)
N Max. boom displacement to bucket center (left side) 531 mm (21 in)
O Max. lift height of stabilizer blade over ground 387 mm (15 in)
P Max. scraping depth of stabilizer blade below ground surface 412 mm (16 in)
Q1 Distance between bucket and stabilizer blade (short stick) 363 mm (14 in)
Q2 Distance between bucket and stabilizer blade (long stick) 267 mm (11 in )
R1 Min. tail end swiveling radius 770 mm (30 in)
R2 Boom swivel radius (center) 2082 mm (82 in)
R3 Boom swivel radius (right) 1964 mm (77 in)
R4 Boom swivel radius (left) 1660 mm (65 in)
S Total running gear length 2021 mm (80 in)
T Running gear length (Turas front idler) 1548 mm (61 in)
W1 Max. tilting angle of boom to the right 50°
W2 Max. tilting angle of boom to the left 75°
X Track width 300 mm (12 in)
Y1 Stabilizer blade width 1570 mm (62 in)
Z Stabilizer blade height 300 mm (12 in)
