BA EZ26 en/us* 1.0 * EZ26_01_900.fm 9-33
Technical data 9
EZ26 VDS
A Height 2524 mm (99 in)
B1 Cabin width 980 mm (39 in)
B2 Upper carriage width 1340 mm (53 in)
B3 Travel gear width 1570 mm (62 in)
C1 Transport length (short stick) 4211 mm (13'-10'')
C2 Transport length (long stick) 4253 mm (13'-11'')
D1 Max. digging depth (short stick) 2427 mm (96 in)
D2 Max. digging depth (long stick) 2627 mm (8'-7'')
E1 Max. vertical digging depth (short stick) 1839 mm (72 in)
E2 Max. vertical digging depth (long stick) 2029 mm (80 in)
F1 Max. digging height (short stick) 4286 mm (14'-0'')
F2 Max. digging height (long stick) 4416 mm (14'-6'')
G1 Max. tilt-out height (short stick) 2957 mm (9'-8'')
G2 Max. tilt-out height (long stick) 3087 mm (10'-2'')
H1 Max. reach at ground level (short stick) 4473 mm (14'-8'')
H2 Max. reach at ground level (long stick) 4673 mm (15'-4'')
K1 Max. digging radius (short stick) 4630 mm (15'-2'')
K2 Max. digging radius (long stick) 4820 mm (15'-10'')
M Max. boom displacement to bucket center (right side) 765 mm (30 in)
N Max. boom displacement to bucket center (left side) 535 mm (21 in)
O Max. lift height of stabilizer blade over ground 390 mm (15 in)
P Max. scraping depth of stabilizer blade below ground surface 410 mm (16 in)
Q1 Distance between bucket and stabilizer blade (short stick) 331 mm (13 in)
Q2 Distance between bucket and stabilizer blade (long stick) 233 mm (9 in)
R1 Min. tail end swiveling radius 760 mm (30 in)
R2 Boom swivel radius (center) 2080 mm (82 in)
R3 Boom swivel radius (right) 1960 mm (77 in)
R4 Boom swivel radius (left) 1660 mm (65 in)
S Total running gear length 2020 mm (80 in)
T Running gear length (Turas front idler) 1550 mm (61 in)
V Angle of inclination VDS 15°
W1 Max. tilting angle of boom to the right 50°
W2 Max. tilting angle of boom to the left 75°
X Track width 300 mm (12 in)
Y1 Stabilizer blade width 1570 mm (62 in)
Z Stabilizer blade height 300 mm (12 in)
