Wacker Neuson RC70 User Manual

Auxiliary equipment
Tachograph
BA RC50_RC70 en 00
195
6.04 Tachograph
6.04.01 Overview
1
2 3
[1] Tachograph [2] Drawer for record sheet
[3] Record sheet
6.04.02 Description
After the electrical system has been switched on, the trip recorder
displays the various machine functions on the record sheet. These
include amongst others:
■
Driving and stopping times
■
Driving speed
■
Vibration amplitude
■
Vibrator speed
1
3 4 5
2
Driving speed
When the machine is moving, the tachograph display shows the driving
speed [1] to one decimal place. The point in the display window indicates
the decimal point. The speed is also shown on the record sheet [2] with
one digit after the decimal point. Example: A peak in the curve at 105 km/
h corresponds to a real driving speed of 10.5 km/h.
