3.09 Set interior, operation and rear mirror
Adjust the mirrors so that you can watch the traffic in the rear of the
machine.
WARNING
Falling off the machine!
Severity injuries or death through falling off the machine while
adjusting the working mirrors.
■
Adjust the working mirrors only when the machine has been safely
parked.
■
To reach the working mirrors use only the ladders, climbing
handholds and steps provided.
NOTE
Clean mirrors at regular intervals.
Replace defective mirrors immediately.
Adjusting the working and rear-view mirrors
The working mirror is adjusted by two persons:
■
The person on the outside of the machine adjusts the working
and rear-view mirrors manually.
■
The driver inside checks the setting from a seated position.
Align the mirror to the work edge of the roller drum/tyre.
Adjust the mirrors so as to ensure that you still see the machine at the
inside of the mirrors. This is the only way of avoiding a blind spot.
Folding in the working and rear-view mirrors
Fold in the mirror.
Turn the mirror holder until the mirror is locked.
NOTE
Fold in and lock the operation mirror before transporting the
machine on a lorry.
Adjusting the inside mirror
Adjust the mirror from the driver’s seated position.
Adjust the mirror so as to ensure that you can see the area behind
the machine in the mirror.
