2.01.02 Stickers on the machine
Below please find a list of warning signs and information signs affixed to
the machine. The images and values may vary according to the type of
machine.
NOTE
For the detailed arrangement of warning and information signs,
please refer to the spare parts catalogue.
NOTE
Be sure to observe the warning signs and information signs
affixed to the machine and strictly follow their instructions.
Information signs
Below is a list of examples of the information signs. The images and
values may vary according to the machine type.
MARGIN
Drive lever function
MARGIN
Hydraulic oil fill level
MARGIN
Filling inlet for hydraulic oil tank
MARGIN
Drain outlet for hydraulic oil tank
MARGIN
12 V socket
