Operation
Driving
BA RC50_RC70 en 00
91
3.16.04 Driving in normal operation
Make ready to drive/release parking brake
Requirement: Diesel engine running, drive lever in position P
Select a gear [3].
Push the drive lever [1] out of position P to the left and into position 0.
a
The indicator light on the parking brake switch [2] is off.
a
Machine is ready to start.
Driving forwards
Preselect the engine speed [4].
Move the drive lever in the F direction.
a
The machine moves forwards.
The final speed depends on the deflection of the drive lever, the
selected gear and the selected engine speed.
Driving backwards
Preselect the engine speed [4].
Move the drive lever in direction R.
a
The reversing lights are switched on.
a
The machine reverses.
The final speed depends on the deflection of the drive lever, the
selected gear and the selected engine speed.
NOTE
For versions equipped with a back-up alarm, an audible signal
is heard as soon as the drive lever is in position R.
