Auxiliary equipment
Dozer blade
200
BA RC50_RC70 en 00
Lubricating the pivot pin
Switch off diesel engine and remove ignition key.
Lubricate lubrication nipple [1] (2 nipples).
Checking/changing the wearing edge
CAUTION
Heavy wear edge!
Injuries caused by crushing or getting caught.
■
The wear edge must be replaced by two persons.
■
Wear personal protective equipment.
Prerequisite: Wearing edge overhang [1] ≤ 3 mm.
Switch off the diesel engine and remove the ignition key.
Undo all screwed connections [2] and remove the screws.
Turn the wearing edge or replace it, if necessary.
Insert all screws and tighten the screwed connections [2].
