Wacker Neuson RD18 User Manual

Tables
Fuses
178
BA RD18 en 01
Component Fuse assignment Fuse
F8 Cold start assistance indicator light 5 A
F9 Not assigned 5 A
F10 Water sprinkling foot pedal 15 A
F11 Additive sprinkling foot pedal, seat heating 15 A
F12 Not assigned
F13 Socket 15 A
F14 Signal horn 15 A
F15 Additive sprinkling pump 15 A
F16 Water sprinkling pump 15 A
F17 Rotating beacon 15 A
F18 Reversing alarm 15 A
F19 Fuel pump, generator 7.5 A
F20 TCU (terminal 15) 7.5 A
F21 TCU (terminal 30) 7.5 A
F35 Dashboard (terminal 30) 20 A
F36 Dashboard (terminal 15) 25 A
F42 Seat belt buckle monitoring device 7.5 A
FT Plug-in socket for fuse test
NOTE
You can use the fusible test receptacle to check a fuse.
The green light-emitted diode (LED) lights up when the fuse is functional.
