Wacker Neuson RD18 User Manual

Operation
Adjusting scrapers
98
BA RD18 en 01
Attach scraper
Switch off diesel engine and remove ignition key.
Turn stop lever [1] to I position.
a
The scraper folds down to the roller drum/tyre.
Moving the scraper away
Switch off diesel engine and remove ignition key.
Turn stop lever [1] to 0 position.
Lift the scraper bracket [2] until the catch latches in.
3.21.03 Bottom drum scraper
1 2
2
Attach scraper
Switch off diesel engine and remove ignition key.
Turn stop lever [1] to I position.
a
The scraper folds up to the roller drum.
Moving the scraper away
Switch off diesel engine and remove ignition key.
Turn stop lever [1] to 0 position.
Press the pedal [2] until the catch latches in.
3.21.04 Tyre scraper
1
2
