Operation
Safety strut
56
BA RD18 en 01
Releasing the steering block
1
4 5 4
2
35
21
4
Undo the retaining bracket [1] from the coupling bar [4].
Remove the bolt [2].
Move the coupling bar [4] from the lower mounting [5] to the upper
mounting [3].
Use the bolt [2] to lock the coupling bar [4] in the upper mounting [3].
Slide the retaining bracket [1] onto the coupling bar [4].
a
The steering block is now released.
