Operating manual Spray wall Basic 8000
13 Spare Parts
Order number 3305595 | Edition 07/2022 39
13.4 SPARE PARTS LIST FOR PRESSURE TANK (UNTIL 06/2021)
6
4
5
1
2
3
P_00483
Pos K Stk Order no. Designation
1 ♦ 3 3306273 Diaphragm
2 3 3306439 Magnet coil 230VAC (until 09/2007)*
2 3 3306274 Magnet coil 24VDC (starting 09/2007)*
2 2 2424184 Magnet coil 24VDC, not ATEX (starting
02/2021)*
3 3 9955654 Valve connector, MSSD-C 230VAC (until
09/2007)*
3 3 3304504 Valve connector, type A 18mm;
0.71inch 24VDC (starting 09/2007)*
4 1 3305056 Pneumatic control unit, complete
5 1 3060190 Pressure regulator 1/4" 0.5–10bar
6 1 114324 Pressure gauge
♦ = Wearing parts
* Before ordering the spare parts, please check the voltage specified on the installed parts.
