6 Assembly and Commissioning
Order number 3305595 | Edition 07/2022 19
6.5 DELIVERY CONDITION OF THE SPRAY WALL
E E
P_00477
Components of the Basic 8000 spray wall
E Grounding sticker
Marked place for mounting a contact washer
Observe the notes in the Chapter Assembly Sequence!
6.6 ASSEMBLY SEQUENCE
A
B
B
C
D
B1
B1
P_00478
Note:
For all component connections, always install M8 hexagon screws with plain washers B
under the screw head A and plain washers B plus spring washers C under the hexagon nut D!
To ensure safe grounding, replace plain washer B with a contact washer B1 at least 2 points
per component connection!
