WAGNER EvoMotion 40-15 User Manual

22
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
Description Units
Pump ratio 40:1
Volume  ow per double stroke cm/cc 15
Maximum operating overpressure MPa 25.0
bar 250
psi 3626
Maximum possible strokes in operation /min. 60
Minimum/maximum air inlet pressure MPa 0.2-0.8
bar 2-8
psi 28-116
Compressed air quality: free from oil and water
Quality standard 7.5.4 according to ISO 8573.1, 2010
7: Particle concentration 5–10mg/m
5: Humidity: pressure dew point ≤ +7 °C
4: Oil content ≤ 5mg/m
Ø air inlet connection (inside thread) mm; inch 8.0; 0.1
Minimum Ø of the compressed air supply line mm; inch 9.0; 0.35
Air consumption at 0.6 MPa; 6 bar; 87 psi per
double stroke
nl 3.9
scf 0.14
Air motor piston diameter mm; inch 80; 3.15
Air motor piston stroke mm; inch 60; 2.4
Sound pressure level at maximum permissible
air pressure*
dB(A) 72
Sound pressure level at 0.6 MPa; 6 bar; 87 psi
air pressure*
dB(A) 69
Sound pressure level at 0.4 MPa; 4 bar; 58 psi
air pressure*
dB(A) 65
Product inlet (outside thread) mm M36x2
Product outlet (outside thread) inch NPS 1/4"
Weight kg 9
lb 19.8
Product pH value pH 3.5 ÷ 9
Maximum product pressure at pump inlet
MPa 2
bar 20
psi 90
Product temperature °C; °F +5...+80; +41...+176
Ambient temperature °C; °F +5...+60; +41...+140
Relative humidity % 10–95 (without condensation)
Allowable inclination for operation
± 10
A rated sound pressure level measured at 1 m distance, LpA1m according to DIN EN 14462: 2005.
5.5.2.1 TECHNICAL DATA
