WAGNER EvoMotion 40-15 User Manual

52
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
12 ACCESSORIES
Order No. Designation
1 2329450 EvoMotion 40-15 PE/T
2 T6145.00A AirCoat regulator set
3 236219 Grounding cable, complete 3 m; 9.8 ft
4 9992504 Separating agent 250 ml
5 9992505 Separating agent 500 ml
= Wearing part
12.1 EVOMOTION 4015 ACCESSORIES
12.2 ACCESSORIES FOR PRODUCT OUTLET
12.3 ACCESSORIES FOR PRODUCT INLET
Order No. Designation
11 2334488 Ball valve R1/4"-G1/4"-PN350-SSt
12 2334472 Ball valve R1/4"-G1/4"-PN350-CS
13 2331752 Return tube DN6-G1/4"-100mm-PA
14 2329046 Return hose DN6-PN310-G1/4"-PA
= Wearing part
Order No. Designation
15 2324158 Suction tube DN16-SSt, complete
16 2324110 Suction hose DN16-SSt, complete
17 2323225 Suction elbow for top reservoir SSt
18 2332169 Top reservoir set, 5 l for piston pump
19 2323396 Suction  lter DN16-18mesh-SSt
Wearing part
