58
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
Air motor spare parts list EM M80
Order No. Designation
1 1 U3B08018060 Air motor EM M80
2 1 F132.91C Motor ange, upper, M50 EM
3 2 L108.06 O-ring
4 1 D608.81 Cylinder motor
5 1 3055157 Hexagon nut with clamp
6 1 9920106 Washer
7
2 G903.06 Steamer
8 1 L413.06 Gasket DE 80
9 1 A164.01 Motor piston
10 1 L802.08 Sliding ring
11 1 L110.06 O-ring
12 1 D404.12 Piston rod, M80 EM
13
2 L109.06 O-ring
14 1 A408.12 Air tube, M80 EM
15 1 T616.00C Motor ange, complete M80 EM, at bottom
16
1 P498.00KNE Reversing valve ISO N/1 (spare parts list see
Chapter 11.3.1.)
17 1 367258 Grounding, complete
18
1 L403.06 Rod seal
19
1 2339340 Sensor below, M80
20 2 K606.02 Lock washer for shaft
21 1 A160.01A Washer
= Wearing parts
= Included in service set.
= Not part of the standard equipment but available as an accessory.
13.3 AIR MOTOR
DANGER
Incorrect maintenance/repair!
Danger to life and equipment damage.
Only a WAGNER service center or a suitably trained person may
carry out repairs and replace parts.
Only repair and replace parts that are listed in the "Spare parts"
chapter and that are assigned to the unit.
Before all work on the device and in the event of work
interruptions:
- Relieve pressure from spray guns and devices.
- Secure spray guns against actuation.
- Switch o the energy/compressed air supply.
- Disconnect the control unit from the mains.
Observe the operating and service manual for all work.
