OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
5.5.3 PERFORMANCE DIAGRAMS
Example
0
180 (18)
<2610>
120 (12)
<1740>
60 (6)
<870>
0
10 20 30 40 50 60
180
<6>
120
<4>
60
<2>
0
0.90
<0.24>
0.75
<0.20>
0.60
<0.16>
0.45
<0.12>
0.30
<0.08>
0.15
<0.04>
0
A
B
C
bar (MPa)
<psi>
nl/min
<scfm>
l/min
<gpm>
A
B
C
240 (24)
<3480>
300 (30)
<4350>
240
<8>
300
<11>
C_00054
Diagram EvoMotion 40-15
Product pressure
Air consumption
Product  ow - water
A = 8 bar (0.8 MPa; 116 psi) air pressure
B = 6 bar; 0.6 MPa; 87 psi air pressure
C = 4 bar; 0.4 MPa; 58 psi air pressure
Stroke frequency /min
Product pressure bar (MPa) psi Air consumption nl/min <scfm>
Water  ow rate l/min <gpm>
Stroke frequency /min
