25
B_04122
2
4
1
3
5
6
7
2
1
3
5
7
B_04123
1
2
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
5.6 PRESSURE REGULATOR UNIT
Ball valve positions:
1 Open: working position
2 Closed: the air motor may still be under
pressure.
closed
open
1 Pressure regulator
2 Ball valve
3 Pressure gauge (air inlet pressure)
4 Pressure gauge for AirCoat air (option)
5 Compressed air inlet
6 Pressure regulator AirCoat (option)
7 Safety and motor pressure relief valve
