46
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
Note:
Before each lling, the nozzle must be removed from the gun. The data in the gun's
operating manual are to be observed.
In case of AirCoat systems, carry out the lling of the system without atomizing air (8).
1. Place empty tank (5) under return tube (4).
2. Place suction hose (7) in the tank with working material (6).
3. Open return valve (3).
4. Slowly open the ball valve (2).
5. Adjust the air pressure on the pressure regulator (1) so that the pump runs
smoothly.
6. Spray until clean working material ows into the tank (5).
7. Close ball valve (2).
8. Close return valve (3).
9. Point the gun (9), without nozzle, into tank (5) and open it.
10. Slowly open the ball valve (2).
11. Spray until clean working material ows from the gun (9).
12. Close ball valve (2).
13. Relieve the system pressure, either by opening the return valve (3) or via the trigger
on the gun (9).
14. When there is no pressure remaining in the system, close the gun (9) or the return
valve (3).
15. Secure the gun.
16. Dispose of the contents of the tank (5) according to the local regulations.
8.2.6 FILLING THE EMPTY PUMP
