3
OPERATING MANUAL
VERSION 12/2015
ORDER NUMBER DOC2333558
Table of Contents
1 ABOUT THESE INSTRUCTIONS 6
1.1 Preface 6
1.2 Warnings, Notices and Symbols in these Instructions 6
1.3 Languages 7
1.4 Abbreviations in the Text 7
1.5 Terminology for the Purpose of this Manual 8
2 CORRECT USE 9
2.1 Device Types 9
2.2 Type of Use 9
2.3 Use in an Explosion Hazard Area 9
2.4 Safety Parameters 9
2.5 Processible Working Materials 10
2.6 Reasonably Foreseeable Misuse 11
2.7 Residual Risks 11
3 IDENTIFICATION 12
3.1 Explosion Protection Identi cation 12
3.2 Identi cation X 12
3.3 Type Plate 13
4 GENERAL SAFETY INSTRUCTIONS 14
4.1 Safety Instructions for the Operator 14
4.1.1 Electrical Equipment 14
4.1.2 Personnel Quali cations 14
4.1.3 Safe Work Environment 14
4.2 Safety Instructions for Sta 15
4.2.1 Safe Handling of WAGNER Spray Devices 15
4.2.2 Grounding the Device 16
4.2.3 Product Hoses 16
4.2.4 Cleaning and Flushing 17
4.2.5 Handling Hazardous Liquids, Varnishes and Paints 18
4.2.6 Touching Hot Surfaces 18
5 DESCRIPTION 19
5.1 Components 19
5.2 Mode of Operation 19
5.3 Protective and Monitoring Equipment 20
5.4 Scope of Delivery 20
5.5 Data 21
5.5.1 Materials of Paint-wetted Parts 21
5.5.2 Technical Data 21
5.5.2.1 Technical Data 22
5.5.2.2 Measurements and Connections 23
5.5.3 Performance Diagrams 24
5.6 Pressure Regulator Unit 25
5.6.1 Safety and Motor Pressure Relief Valve 26
5.6.2 Return Valve 26
